Machine Learning

Flow-Like includes a complete machine learning toolkit built on linfa (Rust’s ML library) and ONNX Runtime for neural network inference. Train models visually without writing code.

Available Algorithms

Classification

Algorithm	Node	Best For
Decision Tree	Fit Decision Tree	Interpretable rules, multi-class
Naive Bayes	Fit Naive Bayes	Fast baseline, Gaussian features
SVM	Fit SVM Multi-Class	High accuracy, complex boundaries

Regression

Algorithm	Node	Best For
Linear Regression	Fit Linear Regression	Continuous predictions, feature importance

Clustering

Algorithm	Node	Best For
K-Means	Fit KMeans	Known cluster count, spherical clusters
DBSCAN	Fit DBSCAN	Unknown cluster count, outlier detection

Dimensionality Reduction

Algorithm	Node	Best For
PCA	Fit PCA	Feature reduction, visualization prep

Deep Learning (ONNX)

Model Type	Node	Best For
Image Classification	ONNX TIMM	Classify images
Object Detection	ONNX YOLO/D-FINE	Detect objects in images
Teachable Machine	Teachable Machine	Quick prototyping

Data Preparation

Input Format

ML nodes expect data in a LanceDB database with:

• A records column: 2D float array (feature matrix)
• A targets column: labels (classification) or values (regression)

Preparing Your Data

┌────────────────────────────────────────────────────────────┐
│                                                            │
│  1. Load Data (CSV, SQL, etc.)                            │
│       │                                                    │
│       ▼                                                    │
│  2. Insert into Database                                   │
│       │                                                    │
│       ▼                                                    │
│  3. Format as records/targets                              │
│       │                                                    │
│       ▼                                                    │
│  4. Split (train/test)                                     │
│       │                                                    │
│       ▼                                                    │
│  5. Train Model                                            │
│                                                            │
└────────────────────────────────────────────────────────────┘

Dataset Splitting

Random Split:

Split Dataset
    │
    ├── Database: (input data)
    ├── Split Ratio: 0.8  (80% train, 20% test)
    │
    ├── Train ──▶ (training database)
    └── Test ──▶ (test database)

Stratified Split (preserves class distribution):

Stratified Split
    │
    ├── Database: (input data)
    ├── Target Column: "label"
    ├── Split Ratio: 0.8
    │
    ├── Train ──▶ (balanced training set)
    └── Test ──▶ (balanced test set)

Use Stratified for Imbalanced Data

If your classes are imbalanced (e.g., 95% vs 5%), always use stratified splitting to ensure both train and test sets have representative samples.

Other Data Operations

Node	Purpose
Shuffle Dataset	Randomize row order
Sample Dataset	Take a random subset

Classification Models

Decision Tree

Decision trees create interpretable if-then rules:

Fit Decision Tree
    │
    ├── Database: (training data)
    ├── Max Depth: 10  (0 = unlimited)
    ├── Min Samples Split: 2
    │
    └── Model ──▶ (trained decision tree)

When to use:

• You need to explain predictions
• Data has clear decision boundaries
• Multi-class classification

Parameters:

Parameter	Effect	Recommendation
Max Depth	Tree complexity	Start with 5-10, increase if underfitting
Min Samples Split	Minimum samples to split	Higher values prevent overfitting

Naive Bayes

Fast Gaussian classifier:

Fit Naive Bayes
    │
    ├── Database: (training data)
    │
    └── Model ──▶ (trained Naive Bayes)

When to use:

• Quick baseline model
• Features are roughly Gaussian
• Fast inference needed

Pros/Cons:

Pros	Cons
Very fast training	Assumes feature independence
Works with small datasets	Less accurate than trees/SVM
Handles multi-class naturally	Sensitive to feature scaling

SVM (Support Vector Machine)

High-accuracy classifier with RBF kernel:

Fit SVM Multi-Class
    │
    ├── Database: (training data)
    │
    └── Model ──▶ (trained SVM ensemble)

When to use:

• Maximum accuracy needed
• Smaller datasets (< 10,000 samples)
• Complex decision boundaries

Notes:

• Uses One-vs-All strategy for multi-class
• Gaussian (RBF) kernel by default
• Slower training than trees/Naive Bayes

Regression Models

Linear Regression

Predict continuous values:

Fit Linear Regression
    │
    ├── Database: (training data with numeric targets)
    │
    └── Model ──▶ (trained linear model)

When to use:

• Predicting continuous values
• Understanding feature importance
• Linear relationship expected

Getting Coefficients:

Get Linear Coefficients
    │
    ├── Model: (trained linear regression)
    │
    └── Info ──▶ {
        coefficients: [0.5, -0.3, 0.8],
        intercept: 2.1,
        n_features: 3
    }

Clustering Models

K-Means

Partition data into k clusters:

Fit KMeans
    │
    ├── Database: (data with records column)
    ├── Clusters: 5  (number of clusters)
    │
    └── Model ──▶ (trained KMeans)

When to use:

• You know the number of clusters
• Clusters are roughly spherical
• Customer segmentation, grouping

Getting Centroids:

Get KMeans Centroids
    │
    ├── Model: (trained KMeans)
    │
    └── Info ──▶ {
        k: 5,
        dimensions: 3,
        centroids: [[...], [...], ...]
    }

DBSCAN

Density-based clustering:

Fit DBSCAN
    │
    ├── Database: (data with records column)
    ├── Epsilon: 0.5  (max distance between points)
    ├── Min Points: 5  (points to form dense region)
    │
    ├── End ──▶ (clustering complete)
    ├── N Clusters ──▶ (number found)
    └── N Noise ──▶ (outliers found)

When to use:

• Unknown number of clusters
• Need to detect outliers/anomalies
• Non-spherical cluster shapes

DBSCAN Returns Counts, Not a Model

Unlike KMeans, DBSCAN doesn’t produce a reusable model—it assigns clusters directly to your data.

Dimensionality Reduction

PCA (Principal Component Analysis)

Reduce feature dimensions:

Fit PCA
    │
    ├── Database: (high-dimensional data)
    ├── N Components: 2  (target dimensions)
    ├── Output Column: "reduced"
    │
    ├── End ──▶ (reduction complete)
    └── Vectors ──▶ (reduced vectors)

When to use:

• Too many features (high-dimensional data)
• Preparing for visualization (reduce to 2-3D)
• Removing noise/redundant features

Making Predictions

The Predict node works with any trained model:

Predict on Database

Predict
    │
    ├── Model: (any trained ML model)
    ├── Mode: "Database"
    ├── Database: (data to predict)
    ├── Input Column: "records"
    ├── Output Column: "predictions"
    ├── Batch Size: 5000
    │
    ├── End ──▶ (predictions complete)
    └── Database ──▶ (with predictions column)

Predict on Vector

For single predictions:

Predict
    │
    ├── Model: (trained model)
    ├── Mode: "Vector"
    ├── Vector: [1.5, 2.3, 0.8, ...]  (features)
    │
    └── Prediction ──▶ "class_a"  (or numeric value)

Model Evaluation

Classification Metrics

Accuracy:

Evaluate Accuracy
    │
    ├── Database: (with predictions & targets)
    ├── Prediction Column: "predictions"
    ├── Target Column: "targets"
    │
    └── Result ──▶ {
        accuracy: 0.92,
        correct: 920,
        total: 1000
    }

Confusion Matrix:

Evaluate Confusion Matrix
    │
    ├── Database: (with predictions & targets)
    ├── Prediction Column: "predictions"
    ├── Target Column: "targets"
    │
    └── Result ──▶ {
        matrix: [[45, 5], [3, 47]],
        precision: [0.94, 0.90],
        recall: [0.90, 0.94],
        f1_score: [0.92, 0.92]
    }

Regression Metrics

Evaluate Regression
    │
    ├── Database: (with predictions & targets)
    ├── Prediction Column: "predictions"
    ├── Target Column: "targets"
    │
    └── Result ──▶ {
        mse: 0.05,
        rmse: 0.22,
        mae: 0.18,
        r_squared: 0.89
    }

Metric Guide:

Metric	Description	Good Value
MSE	Mean Squared Error	Lower is better
RMSE	Root MSE (same units as target)	Lower is better
MAE	Mean Absolute Error	Lower is better
R²	Variance explained	Closer to 1.0

Saving and Loading Models

Save Model

Save ML Model
    │
    ├── Model: (trained model)
    ├── Path: (FlowPath for output)
    │
    └── End

Formats:

• JSON – Human-readable, portable
• Binary – Faster, smaller (Fory format)

Load Model

Load ML Model
    │
    ├── Path: (FlowPath to saved model)
    │
    └── Model ──▶ (loaded model ready for predictions)

ONNX Models (Deep Learning)

For pre-trained neural networks:

Loading ONNX Models

Load ONNX
    │
    ├── Path: (FlowPath to .onnx file)
    │
    └── Session ──▶ (ONNX inference session)

Image Classification (TIMM)

Use models exported from PyTorch Image Models:

ONNX Classification
    │
    ├── Session: (ONNX session)
    ├── Image: (image data)
    ├── Top K: 5
    │
    └── Results ──▶ [
        {class_idx: 281, score: 0.92},
        {class_idx: 282, score: 0.05},
        ...
    ]

Object Detection (YOLO/D-FINE)

Detect objects in images:

ONNX Detection
    │
    ├── Session: (ONNX session)
    ├── Image: (image data)
    ├── Confidence: 0.5
    ├── NMS Threshold: 0.4
    │
    └── Detections ──▶ [
        {class_idx: 0, score: 0.95, x1: 10, y1: 20, x2: 100, y2: 150},
        ...
    ]

Teachable Machine

For Google Teachable Machine models:

Teachable Machine
    │
    ├── Path: (FlowPath to .tflite)
    ├── Labels: (optional labels file)
    ├── Image: (image data)
    │
    └── Results ──▶ [{label: "cat", score: 0.95}, ...]

Model Selection Guide

Use Case	Recommended Model
Quick classification baseline	Naive Bayes
Need to explain predictions	Decision Tree
Maximum accuracy (small data)	SVM
Predict continuous values	Linear Regression
Group data (known K)	K-Means
Find outliers & groups	DBSCAN
Reduce dimensions	PCA
Classify images	ONNX (TIMM)
Detect objects	ONNX (YOLO)
Imbalanced classes	Use Stratified Split first

Complete Example: Customer Churn Prediction

┌────────────────────────────────────────────────────────────┐
│                                                            │
│  Load CSV (customer data)                                  │
│       │                                                    │
│       ▼                                                    │
│  Insert to Database                                        │
│       │                                                    │
│       ▼                                                    │
│  Stratified Split (80/20)                                  │
│       │                                                    │
│       ├──▶ Train Set ──▶ Fit Decision Tree                │
│       │                        │                           │
│       │                        ▼                           │
│       │                   Model ────────────┐              │
│       │                                     │              │
│       └──▶ Test Set ────────────────────────┼──▶ Predict  │
│                                             │       │      │
│                                             │       ▼      │
│                                    Confusion Matrix        │
│                                             │              │
│                                             ▼              │
│                                    Save Model (if good)    │
│                                                            │
└────────────────────────────────────────────────────────────┘

Best Practices

1. Always Split Your Data

Never evaluate on training data—it gives overly optimistic results.

2. Start Simple

Begin with Naive Bayes or Decision Trees, then try more complex models.

3. Use Stratified Splitting for Classification

Especially important when classes are imbalanced.

4. Check Feature Scaling

Some algorithms (SVM, K-Means) are sensitive to feature scales. Consider normalizing.

5. Evaluate Multiple Metrics

Accuracy alone can be misleading. Check precision, recall, and F1.

6. Save Good Models

Don’t retrain every time—save and load trained models.

Troubleshooting

”Model performs poorly”

• Check for data quality issues
• Try a different algorithm
• Increase training data
• Check for class imbalance

”Training is slow”

• Reduce dataset size with sampling
• Use smaller batch sizes
• Try simpler algorithms (Naive Bayes)

“Memory errors”

• Set MAX_RECORDS limit
• Process in batches
• Use sampling for very large datasets

Next Steps

With trained models:

• Data Visualization – Visualize predictions and metrics
• AI-Powered Analysis – Combine ML with GenAI
• Data Loading – Work with more data sources
